Minimum Temperature Rating (°F)
-320
Nominal Size (in.)
1/4"
Outlet Connection (in.)
1/4"
Outlet Connection (mm)
6.4
Pressure Setting (BARG)
6.2
Pressure Setting (PSIG)
90
Recommended Delivery Pressure Range (BARG)
1.7 - 17.2
Recommended Delivery Pressure Range (PSIG)
25 - 250
Width [Face to Face, Diameter] (in.)
2-1/16"
Width [Face to Face, Diameter] (mm)
52.4
Adjustment Method
Screw with locknut
Bonnet Type
Threaded
Connection Type
F.NPT x F.NPT
Material Details
Body: Stainless Steel ASTM A351 CF8; Bonnet and Tube: Stainless Steel ASTM A351 CFBIASTM A479 type 304| Stem: Stainless Steel ASTM A582 S30300|Spring: Stainless Steel ASTMA313 S30200| Packing: Live-loaded PTFE Packing| Gasket: PTFE 25% Glass Fill| Seat Disc.: PCTFE ASTM D1430|Seat Retainer : Brass ASTM B16|Bonnet Screws: ASTM B16 F837|Handwheel: Painted Aluminum| Body:Stainless Steel ASTM A351 CF8
Nominal Size (DN)
8
Product Type
Cryogenic Brass Regulators
Product Warranty
RegO 10 Year
Seat Material Type
Soft
Units
Imperial-Metric
