STR2P

Visit Product Series:

The STR000002 strainers have been designed to retain debris and any other pollution that could be in the lines, and could affect the performance of regulators and other devices. The STR000002 use a Monel filter material. Designed for the handling of cryogenic liquids through bulk tanks, trucks, trailers, ISO-containers and piping configurations.

Markets

Applications

Certification

Documents

Installation Guides

Specifications

Inlet Connection (in.) 1/2"

Inlet Connection (mm) 12.7

Maximum Allowable Working Pressure (BARG) 41.3

Maximum Allowable Working Pressure (PSIG) 600

Maximum Temperature Rating (°C) 74

Maximum Temperature Rating (°F) 165

Minimum Temperature Rating (°C) -196

Minimum Temperature Rating (°F) -320

Nominal Size (in.) 1/2"

Outlet Connection (in.) 1/2"

Outlet Connection (mm) 12.7

Width [Face to Face, Diameter] (in.) 2.84

Width [Face to Face, Diameter] (mm) 72.1

Inlet Connection (DN) 15

Material Details Body: Brass| Cap: Brass| Filter Material: 100 Mesh Monel| Body:Brass

Nominal Size (DN) 15

Outlet Connection (DN) 15

Product Type Y-type Strainers

Product Warranty RegO 10 Year

Units Imperial-Metric

Features & Benefits
